12CrMo9-10 1.7375 A182 F22 2.25Cr 1Mo Steel Forgings for Refinery Hydrogen Service Reactor Nozzles, Manways and Fittings Jiangsu Liangyi

Product Description

Jiangsu Liangyi is an ISO 9001:2015-certified forging manufacturer in China supplying 12CrMo9-10 / W.Nr. 1.7375 (A182 F22) open-die forgings, seamless rolled rings, reactor nozzles and thick-wall fittings to refinery, hydrogen-plant and petrochemical projects in India and worldwide, to EN 10028-2 and ASTM A182 F22.

Why 12CrMo9-10 / 1.7375 for Indian refinery projects

12CrMo9-10 is the 2.25Cr-1Mo standard for high-temperature hydrogen service, sitting high on the API RP 941 Nelson curve for resistance to high-temperature hydrogen attack (HTHA) with elevated-temperature creep strength. For India's refining, petrochemical and hydrogen-plant sectors, 1.7375 suits hydrotreater/hydrocracker reactor nozzles and manways, reformer heater fittings, hydrogen-compressor valve blocks and thick-wall hydrogen-stream fittings.

Documented capability

Refinery/petrochemical: hydrotreater/hydrocracker reactor nozzles/manways, separator heads.

Hydrogen plant/compression: hydrogen-compressor valve blocks, thick-wall hydrogen fittings.

Reformer/heater: charge-heater fittings, flanges.

General: bars, discs, hubs, sleeves, custom forgings.

Product range for Indian buyers

Forged reactor inlet/outlet nozzles and manways; reformer charge-heater fittings; hydrogen-compressor valve blocks; separator head forgings; thick-wall piping fittings (wyes, tees, elbows); flanges; round/square/flat/rectangular bars; discs, hubs, sleeves.

Material data

Chemistry (wt%): C 0.080.15, Cr 2.002.50, Mo 0.901.10. Normalize + temper (or Q+T); PWHT-simulation testing available; 2.25Cr-1Mo Nelson curve for HTHA. Same grade across 12CrMo9-10 / 1.7375 / A182 F22 / A387 Gr.22.

Standards & quality

Manufactured to EN 10028-2, EN 10222-2, ASTM A182 F22, A387 Gr.22; API RP 941 Nelson-curve grade; EAF + LF/VD melting; 100% UT; full chemistry; impact testing; EN 10204-3.1 / 3.2.

Commercial & logistics

Lead time by project; FOB Shanghai / CIF to Nhava Sheva, Mundra, Chennai, Kandla, Visakhapatnam.

Enquire with Jiangsu Liangyi: sales@jnmtforgedparts.com +86-13585067993 Jiangyin, Jiangsu, China.

Jiangsu Liangyi is an independent manufacturer; designations indicate the material supplied.
