1.4922 X20CrMoV11-1 Martensitic Cr Mo V Steel Forgings for Steam Turbine Rotors, Blades and Bolts Bars, Rings and Discs Jiangsu Liangyi

Product Description

Jiangsu Liangyi is an ISO 9001:2015-certified forging manufacturer in China supplying 1.4922 / X20CrMoV11-1 open-die forgings, seamless rolled rings, discs and bars to steam-turbine, power-generation and high-pressure-valve projects in India and worldwide, to EN 10269 and DIN 17240.

Why 1.4922 / X20CrMoV11-1 for Indian steam-turbine projects

"X20" is a martensitic Cr-Mo-V creep-resisting steel with a long, well-characterized creep-rupture database and continuous service capability to 565 C, making it the benchmark grade for HP/IP steam-turbine rotors, discs, blades, bolts and valve components. For India's power-generation and high-pressure-equipment sectors, 1.4922 suits rotor shafts, discs, blades, bolts and valve stems/bodies.

Documented capability

Steam turbines/power: rotor shafts, discs, blades/vanes, turbine bolts/studs, couplings.

Valves/high-pressure equipment: valve stems, spindles, bodies.

High-temperature bolting: studs, bolts, fasteners to 565 C.

General: hollow bars, sleeves, hubs, shafts, custom forgings.

Product range for Indian buyers

Forged rotor shafts and discs; turbine blades and vanes; turbine bolts and studs; valve stems, spindles and bodies; couplings and shafts; round/square/flat/rectangular bars; hollow bars, sleeves, hubs.

Material data

Chemistry (wt%): C 0.170.23, Si 0.50, Mn 0.400.90, Cr 10.0011.50, Mo 0.801.20, V 0.250.35, Ni 0.70. Quench + temper; continuous service to 565 C. Same grade across 1.4922 / X20CrMoV11-1 / X20CrMoV12-1.

Standards & quality

Manufactured to EN 10269, DIN 17240, ASME SB; EAF/AOD/VOD melting + optional ESR; 100% UT; full chemistry; mechanical/creep-rupture testing on request; EN 10204-3.1 / 3.2.

Commercial & logistics

Lead time by project; FOB Shanghai / CIF to Nhava Sheva, Mundra, Chennai, Kandla, Visakhapatnam.

Enquire with Jiangsu Liangyi: sales@jnmtforgedparts.com +86-13585067993 Jiangyin, Jiangsu, China.

Jiangsu Liangyi is an independent manufacturer; designations indicate the material supplied.
