Custom HP-IP and LP monoblock turbine rotor shafts

Get a Price/Quote

MOQ : 1 Unit

Custom HP-IP and LP monoblock turbine rotor shafts Specification

Material
Alloy steel (typically forged steel such as ASTM A182 F22 or X12CrMoWVNbN10-1-1 as per turbine requirements)

Texture Type
Machined & polished surface finish

Quality Level
Turbine-grade, complying with international standards (e.g., ISO, ASME)

Coating
Anti-corrosive protective or phosphate coating

Length
Custom-ranges from 2 meters to 8 meters depending on design

Diameter
Custom-typically 200 mm to 1200 mm

Hardness
250-350 HB (Brinell Hardness)

Precision
High precision, ISO IT6-IT7 tolerance class

Roundness
0.02 mm deviation

Thickness
Application-specific; usually core-determined and varies 100 mm to 600 mm

Weight
Typically 2 to 20 tons depending on size and application

Turbine Type
Compatible with steam, gas, and water turbine assemblies

End Finish
Customized with keyways, flanges, and threads as per client drawing

Heat Treatment
Quenched and tempered for optimal strength and fatigue resistance

Application
Used in High Pressure (HP), Intermediate Pressure (IP), and Low Pressure (LP) monoblock turbine rotors for power plants

Non-Destructive Testing (NDT)
Ultrasonic and Magnetic Particle Inspection to ensure internal integrity

Production Method
Closed die forging, precision machining, and multi-stage grinding

Balancing
Dynamically balanced as per ISO 1940 G 1.0/G 2.5 standard

Surface Roughness
Ra 0.8 m for bearing journals

Custom HP-IP and LP monoblock turbine rotor shafts Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Custom HP-IP and LP monoblock turbine rotor shafts

Get the prime solution for your power plant needs with our in-demand Custom HP-IP and LP monoblock turbine rotor shafts. These magnificent shafts are crafted using closed die forging, precision machining, and multi-stage grinding, guaranteeing an astounding level of dimensional accuracy and durability. Each shaft is a must-have, dynamically balanced as per ISO 1940 G 1.0/G 2.5 and heat treated for exceptional strength and fatigue resistance. Suitable for steam, gas, or water turbines, our export-quality shafts are meticulously inspected by Ultrasonic and Magnetic Particle methods, with a premium anti-corrosive finish. Customization is available as per your exact specifications.

Custom HP-IP and LP Monoblock Turbine Rotor Shafts: Applications & Features

Our Custom HP-IP and LP monoblock turbine rotor shafts are specifically designed for high-performance use in the energy sector, serving high, intermediate, and low-pressure turbine rotors in power plants. Engineered for both specific and general industrial use, each shaft features exceptional fatigue resistance, dynamic balancing, and stringent non-destructive internal integrity checks. The machined and polished finish, custom end detailing, and international quality compliance ensure a reliable, robust, and adaptable component for demanding turbine applications.

Delivery Time, Payment Terms & Packaging for Turbine Rotor Shafts

Experience quick dispatch and express shipping options with our turbine rotor shafts, ensuring minimal downtime for your projects. Delivery schedules are established upon ordering and confirming design details. Pricing is available upon request, with flexible payment terms offered to meet various client requirements. Each shaft is securely packaged in robust, industry-standard crates, protecting the product during both domestic and international transport. Count on us for a seamless export solution from China, tailored to your project timeline.

FAQ's of Custom HP-IP and LP monoblock turbine rotor shafts:

Q: How are the custom HP-IP and LP monoblock turbine rotor shafts manufactured?

A: Each shaft is produced using closed die forging, followed by precision machining and multi-stage grinding to achieve high dimensional accuracy and surface finish. The process also includes dynamic balancing and various non-destructive tests.

Q: What turbine applications are these shafts best suited for?

A: These shafts are specifically designed for steam, gas, and water turbine assemblies in power plants, fitting high, intermediate, and low-pressure monoblock rotor requirements.

Q: What surface and heat treatment processes are implemented on the shafts?

A: They are quenched and tempered for optimal hardness and fatigue resistance. A machined and polished surface finish is achieved, with additional anti-corrosive or phosphate coatings applied as per order.

Q: Where are the products exported from, and which standards do they follow?

A: Our turbine rotor shafts are exported from China and manufactured to meet international standards like ISO and ASME, ensuring turbine-grade quality and global compatibility.

Q: What are the benefits of ordering customized shafts versus standard products?

A: Custom shafts allow precise matching of design specifications, including size, core thickness, end finishes, and material grades, leading to improved performance, easier installation, and longer service life.

Q: When can I expect delivery after placing an order?

A: Once your order and design details are confirmed, quick dispatch and express shipping ensure your custom shafts are delivered in alignment with your project's deadline.
