1.4507 X2CrNiMoCuN25 6 3 S32520 Copper Super Duplex Forgings for Seawater, Oil and Gas and Acid Service Flanges, Valves and Shafts Jiangsu Liangyi

Product Description

Jiangsu Liangyi is an ISO 9001:2015-certified forging manufacturer in China supplying 1.4507 / X2CrNiMoCuN25-6-3 (S32520) open-die forgings, rings, flanges and bars to seawater, offshore oil-and-gas, desalination and acid-process projects in India and worldwide, to ASTM A182 / A240.

Why 1.4507 / S32520 for Indian seawater and acid projects

1.4507 is a copper-bearing super duplex stainless (25Cr-6.5Ni-3.5Mo-Cu-N) with roughly double austenitic strength, a PREN 40 for seawater/chloride pitting and crevice resistance, high resistance to chloride SCC, and copper-enhanced resistance in sulphuric/phosphoric acid. For India's offshore oil-and-gas, desalination, chemical and marine sectors, it suits flanges, valves, pump shafts and acid-process components.

Documented capability

Seawater/offshore: equipment components, pump shafts, impellers, wear parts.

Desalination: desalination plant parts, high-pressure components.

Chemical/acid: flanges, valves, pumps for sulphuric/phosphoric acid.

Marine/general: marine hardware, fasteners; tubesheets, nozzles, seal/guide rings, bars, discs, hubs, sleeves, custom forgings.

Product range for Indian buyers

Forged seawater and offshore oil-and-gas equipment components; desalination plant parts; chemical and acid-process flanges, valve bodies and pump components; pump shafts, impellers and wear parts; marine hardware and fasteners; heat-exchanger tubesheets; reactor and vessel nozzles; seal/guide rings; round/square/flat/rectangular bars; discs, hubs, sleeves.

Material data

Chemistry (UNS S32520 / EN 1.4507, wt%): C 0.030, Cr 24.026.0, Ni 5.58.0, Mo 3.04.0, Cu 0.52.0, N 0.200.35. PREN 40; solution anneal 10501120 C + water quench. Trade-equivalents Ferralium 255 / UR 52N+.

Standards & quality

Manufactured to ASTM A182 / A240, EN 10088-3; EAF + AOD/VOD melting (ESR available); 100% UT + PT; full chemistry (Cr/Mo/N/Cu verification); ferrite / pitting testing on request; EN 10204-3.1 / 3.2.

Commercial & logistics

Lead time by project; FOB Shanghai / CIF to Nhava Sheva, Mundra, Chennai, Kandla, Visakhapatnam.

Enquire with Jiangsu Liangyi: sales@jnmtforgedparts.com +86-13585067993 Jiangyin, Jiangsu, China.

Jiangsu Liangyi is an independent manufacturer; designations indicate the material supplied.
